Product Name:AMAXX® receptacle combination
Part No.:920037.
Fitted with:1 CEE 16A, 5p, 400V
2 SCHUKO® 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
1 MCB 16A, 3p, C
2 MCB´s 16A, 1p, C .
Pre-fuse max:63A.
InA :30A.
RDF:0 MENNEKES 920045. 95.
Connection/feeder cable:for 1 cable up to 5 x 10mm² 920045
Enclosure size:260 x 225 mm (H x W).
Protection type IP44.
highly resistant to chemicals made of AMELAN®.
with highly heat resistan contact carrier and nickel plated contacts MENNEKES 920045.
pre-wired for installation.
enclosure front cover grey RAL 7000.
hinged to the side.
fusing behind a transparent cover.Product Name:AMAXX® receptacle combination
Part No.:920006.
Fitted with:1 CEE 16A, 5p, 400V
2 SCHUKO® 16A, 230V.
Fusing:1 MCB 16A, 3p, D
2 MCB´s 16A, 1p, C.
Pre-fuse max.:63A.
InA:32A.
RDF:1 MENNEKES 920045.
Connection/feeder cable:for 1 cable up to 5 x 10 mm².
Enclosure size:260 x 225 mm (H x W).
Protection type IP44.
pre-wired for installation MENNEKES AMAXX receptacle combination.
hinged to the side.
enclosure and insert made of AMAPLAST MENNEKES AMAXX receptacle combination.
fusing behind a transparent cover.Product Name:DELTA-BOX receptacle combination
Part No.:92594.
Fitted with:3 CEE 16A, 4p, >50 - 500V, 100-300 Hz.
Connection/feeder cable:for 1 cable up to 5 x 10 mm² MENNEKES AMAXX receptacle combination.
Protection type:IP44.
pre-wired for installation.
with cable grip and installed hanging hook.
enclosure and insert made of AMAPLAST.Product Name:EverGUM receptacle combination
Part No.:70724.
Fitted with:8 SCHUKO® 16A, 230V.
Fusing:1 RCD 40A, 4p, 0.03A
4 MCB´s 16A, 1p, B.
Pre-fuse max:16A.
InA :16A.
RDF:1.
Connection/feeder cable:2 m H07RN-F5G2 920045. 5 with CEE-plug 16A, 5p, 400V.
Enclosure size:306 x 230 x 288 mm (L x W x H).
Prootection type IP44 MENNEKES 920045.
solid rubber enclosure, signal yellow RAL 1003.
pre-wired for installation.
